Brand: Redarc
REDARC'S newly designed 20 Amp Solar Regulator comes with the Anderson SB50 connectors and works perfectly with a range of permanent and portable solar products. REDARC's 20 Amp Solar Regulator acts as the go between to transfer power generated from solar panels to the battery.
Featuring multistage charging; boost, absorption and float, REDARC's 20 Amp Solar Regulator ensures that the correct charge is supplied safely and efficiently to the battery and will protect it from over charging.
It will work with multiple chemistry batteries including AGM, Standard and Calcium*, and is ideal for permanent installation or portable systems, and has multiple levels of protection including over temperature, over charge and reverse polarity.
What's more set up is now even easier thanks to genuine industry standard Anderson SB50 connectors. These high quality Anderson plugs are simple and fast to connect with no screw terminals and no risk of poor connections from frayed wires or loose terminals just plug and play!
Features
Optional Monitor
*Battery default setting is AGM. REDARC recommends the purchase of the REDARC Solar Remote Monitor to change battery types and configuration settings.
(SRPA0240)
| Attribute name | Attribute value |
|---|---|
| Input (Operating) Voltage | 12V/24V |
| Maximum Power Rating | 240/480W |
| Output Current Rating (Cont.) | 20A |
| Charge Type | PWM 50Hz |
| Waterproof IP rating | Yes - IP55 |
| Operating Temperature | -35°C to +55°C |
| Height (mm) | 28 |
| Length (mm) | 153 |
| Width (mm) | 103 |
| Weight (kg) | 0.52 |
| Warranty | 2 Years |
| SKU | SRPA0240 |
| Brand | Redarc |
